Electric Diaphragm Pump

Documents

Specifications


	2FA-EC Series

Max. Pump Performance Range
Capacity (GPM):	20
Suction Lift - Vertical (ft):	20
Suction Lift - Horizontal (ft):	75
Total Discharge Head - Vertical (ft):	50
Total Discharge Head - Horizontal (ft):	300
Solids Handling/Particle Size (inch):	1.25
Suspended Solids By Volume:	50%
Continuous Liquid Temperature:	140°F
Connection Size (inch):	1.5" or 2" FNPT (your choice)
Standard Connection Type:	Threaded FNPT
No. of Diaphragms:	Single
Materials of Construction
Diaphragm Size (inch):	7" OD
Diaphragm:	Blended Rubber with Fabric Reinforcement
Flapper Check Valves:	Reinforced Viton
Clamping Plates:	Steel
Pump Body:	Aluminum
Bearing:	Cam Follower
Crankarm:	Steel
Inlet/Outlet Flanges:	Aluminum
Check Valve Seat:	Aluminum
Pump Rod:	Steel
Gaskets:	Neo-Nylon
Lubrication:	Alemite Grease Fitting
Base:	Aluminum
Drive Options
Average Pump Speed (RPM):	60
Constant Speed Gear Reducer:	Siemens, SEW Eurodrive or Equal
Electric Motor - HP @ 1800 RPM:	1
Single Phase; 60 Hz - Voltage(s):	115/208-230V
Three Phase; 60 Hz - Voltage(s):	208-360V, 230-460V or 360-575V
DC Permanent Magnet:	24V DC
Standard Motor Enclosure***:	TEFC
Pneumatic Air Motor (For models ending -AP):	1.1HP (41 CFM; 80 PSI)
ADDITIONAL INFORMATION**:
Approx. Pump Weight:	95 lb [43 kg]
Approx. Pump Dimensions (inches):	24 x 16 x 15 (LxWxH)
Approx. Pump Dimensions (cm):	63.5 x 40.6 x 38 (LxWxH)

			Standard model Featuring single phase or three phase motors. Heavy duty Siemens or SEW Eurodrive gear box.
			DC Motor Ideal for truck mount or vessel mount applications featuring a heavy duty Leeson® DC motor with 60 Hz; 115-230 V, single phase power.
			E-Z Transport Package A Heavy duty lifting package mounted directly to the pump for added durability. Transport your Mud Sucker from site to site more easily.
			Wheel kit The heavy duty wheel kit helps you maneuver your 2FA-EC anywhere with a heavy duty frame.
			Air Driven The heavy duty wheel kit helps you maneuver your 2FA-EC anywhere with a heavy duty frame. >Details
			Pump Out System A complete pump out system designed specifically for marinas. >Details
			Waste Tank Pump This versatile mounting system can be used on farms for manure pumping or fertilizer distribution and for waste collection at marinas and campgrounds >Details


		1. Pump Body The Mud Sucker pump body makes all the difference. We design all FA Series with a body designed to move tough fluids without clogging.
		2. Gear Box Wastecorp only selects gear box and motor manufacturers with demonstrated expertise in the fluid handling business. We specify SEW Eurodive and Siemens gear boxes on Mud Sucker Pumps.
		3. Diaphragm Heavy duty 7" OD rubber/nylon blended diaphragm to pump tough slurry and fluids.
		4. Heavy Duty Castings Make no mistake, all pumps are not made alike. Mud Sucker castings are made of premium marine grade aluminum for high use environments not to be confused with throw away makes.
		Optional Pressure Relief Valve We highly recommend that you specify your new Mud Sucker 2FA with an optional pressure relief valve system. This helps to prevent damage to your pump in the event of a closed valve in your system and an emergency shut down.

	Optional Add-On Hosing & Fittings	Part Number
	Camlock Adapters, Male (Part F)	60462-00
	Clear Swing Check Valve, 2” FNPT	60536-00
	Discharge Lay flat Hose (Blue), Part C&E Camlocks, 2” x 50ft length (PN: )	51333-00
	Non-Collapsible EPDM (Grn/Blk) Hose, Part C&KC Camlocks, 2” x 20ft length	60718-00
	Strainer, Sq Hole (Solids), 2” FNPT	34383-00
	Strainer, Rd Hole (Non-Clog), 2” FNPT	60583-00
	Optional Electrical Components
	Variable Frequency Drive with Keypad mounted directly on gear motor (1HP; 3 Phase Only)	Call
	Manual Push Starter in NEMA 12 Enclosure with motor protection & pigtail	61492-00
	Manual Push E-Stop Button Starter in NEMA 12 enclosure with overload contractor, transformer & pigtail	61491-00
	Optional Spare Parts Kits
	Flapper Valve Assembly	Call
	Basic Spare Parts Kit (Diaphragm & Flappers Only)	61285-00
	Comprehensive Spare Parts Kit (Diaphragm, Flappers, Weights and Hardware)	61284-00
	Wheel mount kit with handles	61315-00

Overall Rating

5/5

Nice pump

Pumpr34

From:

Atlanta, GA

Application:

Waste oil pumping

Average GPM:

10-20

I bought the Mud Sucker 2FA-EC for oil spill clean up pumping, oily water removal from barges. Their engineering people switched the diaphragms for me to be oil resistant. We use it every day and works good.

5/5

Excellent Dewatering Pump

Hester1

From:

Ypsilanti, MI

Application:

Construction

Average GPM:

10-20

We have used a lot of pump in our construction company over the years. I am very impressed with the durability of these pumps for the public works dewatering jobs we do. We're adding two more to the fleet this year, I need a quote on these?

Do you own a Mud Sucker 2FA Series? Rate this pump for your application
